OH Adapter sleeves for metric shafts

Drawing

Datasheet

Adapter sleeve	Dimensions									Mass
Adapter sleeve	d1	d	d3	B1	B2	B3	G	G1	A	Mass
–	mm	mm	mm	mm	mm	mm	-	-	-	kg
OH 2344 H	200	220	280	186	35	–	Tr 220x4	M 6	4,2	17,0
OH 2348 H	220	240	300	199	37	–	Tr 240x4	M 6	4,2	19,0
OH 2352 H	240	260	330	211	39	–	Tr 260x4	M 6	4,2	23,0
OH 2356 H	260	280	350	224	41	–	Tr 280x4	M 6	4,2	27,0
OH 3044 H	200	220	260	126	30	41	Tr 220x4	M 6	4,2	9,90
OH 3048 H	220	240	290	133	34	46	Tr 240x4	M 6	4,2	12,0
OH 3052 H	240	260	310	145	34	46	Tr 260x4	M 6	4,2	13,5
OH 3056 H	260	280	330	152	38	50	Tr 280x4	M 6	4,2	16,0
OH 3060 H	280	300	360	168	42	54	Tr 300x4	M 6	4,2	20,5
OH 3064 H	300	320	380	171	42	55	Tr 320x5	M 6	4	22,0
OH 3068 H	320	340	400	187	45	58	Tr 340x5	M 6	4	27,0
OH 3072 H	340	360	420	188	45	58	Tr 360x5	M 6	4	29,0
OH 3076 H	360	380	450	193	48	62	Tr 380x5	M 6	4	35,5
OH 3080 H	380	400	470	210	52	66	Tr 400x5	M 6	4	40,0
OH 3084 H	400	420	490	212	52	66	Tr 420x5	M 6	4	47,0
OH 3088 H	410	440	520	228	60	77	Tr 440x5	M 8	6,5	65,0
OH 3092 H	430	460	540	234	60	77	Tr 460x5	M 8	6,5	71,0
OH 3096 H	450	480	560	237	60	77	Tr 480x5	M 8	6,5	75,0
OH 30/500 H	470	500	580	247	68	85	Tr 500x5	M 8	6,5	82,0
OH 30/530 H	500	530	630	265	68	90	Tr 530x6	M 8	6	105
OH 30/560 H	530	560	650	282	75	97	Tr 560x6	M 8	6	112
OH 30/600 H	560	600	700	289	75	97	Tr 600x6	G 1/8	8	147
OH 30/630 H	600	630	730	301	75	97	Tr 630x6	M 8	6	138
OH 30/670 H	630	670	780	324	80	102	Tr 670x6	G 1/8	8	190
OH 30/710 H	670	710	830	342	90	112	Tr 710x7	G 1/8	8	228
OH 30/750 H	710	750	870	356	90	112	Tr 750x7	G 1/8	8	246
OH 30/800 H	750	800	920	366	90	112	Tr 800x7	G 1/8	10	302
OH 30/850 H	800	850	980	380	90	115	Tr 850x7	G 1/8	10	341
OH 30/900 H	850	900	1 030	400	100	125	Tr 900x7	G 1/8	10	387
OH 30/950 H	900	950	1 080	420	100	125	Tr 950x8	G 1/8	10	424
OH 30/1000 H	950	1 000	1 140	430	100	125	Tr 1000x8	G 1/8	10	470
OH 30/1060 H	1 000	1 060	1 200	447	100	125	Tr 1060x8	G 1/8	12	571
OH 3144 H	200	220	280	161	35	–	Tr 220x4	M 6	4,2	15,0
OH 3144 HTL	200	220	260	161	30	41	Tr 220x4	M 6	4,2	14,3
OH 3148 H	220	240	300	172	37	–	Tr 240x4	M 6	4,2	16,5
OH 3148 HTL	220	240	290	172	34	46	Tr 240x4	M 6	4,2	15,1
OH 3152 H	240	260	330	190	39	–	Tr 260x4	M 6	4,2	21,0
OH 3152 HTL	240	260	310	190	34	46	Tr 260x4	M 6	4,2	17,7
OH 3156 H	260	280	350	195	41	–	Tr 280x4	M 6	4,2	23,0
OH 3156 HTL	260	280	330	195	38	50	Tr 280x4	M 6	4,2	19,3
OH 3160 H	280	300	380	208	40	53	Tr 300x4	M 6	4,2	29,0
OH 3164 H	300	320	400	226	42	56	Tr 320x5	M 6	4	32,0
OH 3168 H	320	340	440	254	55	72	Tr 340x5	M 6	4	50,0
OH 3172 H	340	360	460	259	58	75	Tr 360x5	M 6	4	56,0
OH 3176 H	360	380	490	264	60	77	Tr 380x5	M 6	4	61,5
OH 3180 H	380	400	520	272	62	82	Tr 400x5	M 6	4	73,0
OH 3184 H	400	420	540	304	70	90	Tr 420x5	M 6	4	80,0
OH 3188 H	410	440	560	307	70	90	Tr 440x5	M 8	6,5	95,0
OH 3192 H	430	460	580	326	75	95	Tr 460x5	M 8	6,5	119
OH 3196 H	450	480	620	335	75	95	Tr 480x5	M 8	6,5	135
OH 31/500 H	470	500	630	356	80	100	Tr 500x5	M 8	6,5	145
OH 31/530 H	500	530	670	364	80	105	Tr 530x6	M 8	6	161
OH 31/560 H	530	560	710	377	85	110	Tr 560x6	M 8	6	185
OH 31/600 H	560	600	750	399	85	110	Tr 600x6	G 1/8	8	234
OH 31/630 H	600	630	800	424	95	120	Tr 630x6	M 8	6	254
OH 31/670 H	630	670	850	456	106	131	Tr 670x6	G 1/8	8	340
OH 31/710 H	670	710	900	467	106	135	Tr 710x7	G 1/8	8	392
OH 31/750 H	710	750	950	493	112	141	Tr 750x7	G 1/8	8	451
OH 31/800 H	750	800	1 000	505	112	141	Tr 800x7	G 1/8	10	535
OH 31/850 H	800	850	1 060	536	118	147	Tr 850x7	G 1/8	10	616
OH 31/900 H	850	900	1 120	557	125	154	Tr 900x7	G 1/8	10	677
OH 31/950 H	900	950	1 170	583	125	154	Tr 950x8	G 1/8	10	738
OH 31/1000 H	950	1 000	1 240	609	100	154	Tr 1000x8	G 1/8	10	842
OH 31/1060 H	1 000	1 060	1 300	622	125	154	Tr 1060x8	G 1/8	12	984
OH 3260 H	280	300	380	240	40	53	Tr 300x4	M 6	4,2	32,0
OH 3264 H	300	320	400	258	42	56	Tr 320x5	M 6	4	35,0
OH 3268 H	320	340	440	288	55	72	Tr 340x5	M 6	4	51,5
OH 3272 H	340	360	460	299	58	75	Tr 360x5	M 6	4	60,5
OH 3276 H	360	380	490	310	60	77	Tr 380x5	M 6	4	69,5
OH 3280 H	380	400	520	328	62	82	Tr 400x5	M 6	4	87,0
OH 3284 H	400	420	540	352	70	90	Tr 420x5	M 6	4	96,0
OH 3288 H	410	440	560	361	70	90	Tr 440x5	M 8	6,5	117
OH 3292 H	430	460	580	382	75	95	Tr 460x5	M 8	6,5	134
OH 3296 H	450	480	620	397	75	95	Tr 480x5	M 8	6,5	153
OH 32/500 H	470	500	630	428	80	100	Tr 500x5	M 8	6	170
OH 32/530 H	500	530	670	447	80	105	Tr 530x6	M 8	6	192
OH 32/560 H	530	560	710	462	85	110	Tr 560x6	M 8	6	219
OH 32/600 H	560	600	750	487	85	110	Tr 600x6	G 1/8	8	278
OH 32/670 H	630	670	850	558	106	131	Tr 670x6	G 1/8	8	401
OH 32/710 H	670	710	900	572	106	135	Tr 710x7	G 1/8	8	459
OH 32/750 H	710	750	950	603	112	141	Tr 750x7	G 1/8	8	526
OH 3944 H	200	220	260	96	30	41	Tr 220x4	M 6	4,2	7,95
OH 3948 H	220	240	290	101	34	46	Tr 240x4	M 6	4,2	11,0
OH 3952 H	240	260	310	116	34	46	Tr 260x4	M 6	4,2	11,7
OH 3956 H	260	280	330	121	38	50	Tr 280x4	M 6	4,2	15,3
OH 3960 H	280	300	360	140	42	54	Tr 300x4	M 6	4,2	20,0
OH 3964 H	300	320	380	140	42	55	Tr 320x5	M 6	4	21,5
OH 3968 H	320	340	400	144	45	58	Tr 340x5	M 6	4	24,5
OH 3972 H	340	360	420	144	45	58	Tr 360x5	M 6	4	25,2
OH 3972 HE	340	360	420	144	45	58	Tr 360x5	M 6	4	25,2
OH 3976 H	360	380	450	164	48	62	Tr 380x5	M 6	4	31,5
OH 3980 H	380	400	470	168	52	66	Tr 400x5	M 6	4	35,0
OH 3984 H	400	420	490	168	52	66	Tr 420x5	M 6	4	36,0
OH 3984 HE	400	420	490	168	52	66	Tr 420x5	M 6	4	36,0
OH 3988 H	410	440	520	189	60	77	Tr 440x5	M 8	6,5	58,0
OH 3992 H	430	460	540	189	60	77	Tr 460x5	M 8	6,5	60,0
OH 3996 H	450	480	560	200	60	77	Tr 480x5	M 8	6,5	66,0
OH 3996 HE	450	480	560	200	60	77	Tr 480x5	M 8	6,5	66,0
OH 39/500 H	470	500	580	208	68	85	Tr 500x5	M 8	6,5	74,3
OH 39/500 HE	470	500	580	208	68	85	Tr 500x5	M 8	6,5	74,3
OH 39/530 H	500	530	630	216	68	90	Tr 530x6	M 8	6	87,9
OH 39/530 HE	500	530	630	216	68	90	Tr 530x6	M 8	6	87,9
OH 39/560 H	530	560	650	227	75	97	Tr 560x6	M 8	6	95,0
OH 39/560 HE	530	560	650	227	75	97	Tr 560x6	M 8	6	95,0
OH 39/600 H	560	600	700	239	75	97	Tr 600x6	G 1/8	8	127
OH 39/600 HE	560	600	700	239	75	97	Tr 600x6	G 1/8	8	127
OH 39/630 H	600	630	730	254	75	97	Tr 630x6	M 8	6	124
OH 39/630 HE	600	630	730	254	75	97	Tr 630x6	M 8	6	124
OH 39/670 H	630	670	780	264	80	102	Tr 670x6	G 1/8	8	162
OH 39/710 H	670	710	830	286	90	112	Tr 710x7	G 1/8	8	183
OH 39/710 HE	670	710	830	286	90	112	Tr 710x7	G 1/8	8	183
OH 39/750 H	710	750	870	291	90	112	Tr 750x7	G 1/8	8	211
OH 39/750 HE	710	750	870	291	90	112	Tr 750x7	G 1/8	8	211
OH 39/800 H	750	800	920	303	90	112	Tr 800x7	G 1/8	10	259
OH 39/800 HE	750	800	920	303	90	112	Tr 800x7	G 1/8	10	259
OH 39/850 H	800	850	980	308	90	115	Tr 850x7	G 1/8	10	288
OH 39/850 HE	800	850	980	308	90	115	Tr 850x7	G 1/8	10	288
OH 39/900 H	850	900	1 030	326	100	125	Tr 900x7	G 1/8	10	330
OH 39/900 HE	850	900	1 030	326	100	125	Tr 900x7	G 1/8	10	330
OH 39/950 H	900	950	1 080	344	100	125	Tr 950x8	G 1/8	10	363
OH 39/1000 H	950	1 000	1 140	358	100	125	Tr 1000x8	G 1/8	10	407
OH 39/1060 H	1 000	1 060	1 200	372	100	125	Tr 1060x8	G 1/8	12	490
